APT 109 Pneumatic Rock Drill

APT 109 Pneumatic Rock Drill

$1,017.00

Add to Cart
APT 109 Pneumatic Rock Drill
APT 109 Pneumatic Rock Drill
$1,017.00
Free Shipping (Ground shipping to lower 48)

Weighing only 9lbs, theAPT Model 109Rock Drill & Utility Drill is the lightest tool American Pneumatic makes. It is the ideal tool for drilling holes for anchor bolts, as well as for small dowel hole drilling. The stop rotation feature easily converts the tool from a drilling machine to a percussion only tool.

Features:

  • Right-hand rotation
  • Lightweight, aluminum cast, D-style handle
  • Inside trigger for better control and safety
  • Deep case hardened alloy steel cylinder
  • Rubber dust excluder helps protect internal parts form dust and debris
  • Ball type retainer allows for quick change-out of drill bits

Specifications

SKU
Product Name
Vendor SKU
Chuck Size (in)
Power Source
Weight Class
Min Air consumption (cfm)
Max Air Consumption (cfm)
Tool Weight (lb)
Impact Rate (bpm)
Wet or Dry
Bore (in)
Stroke (in)
Length (in)
Air Inlet (in)
APT17643
APT 109 Pnuematic Rock Drill - 3/4 x 3-1/4"
17643
3/4 Round x 3-3/4
Pneumatic
15
20
20
9
3400
Dry
1-1/4
1
15
3/8 Female NPT
